| Frequency Range |
| N9010B-503 | Frequency Range, 10 Hz to 3.6 GHz |
| N9010B-507 | Frequency Range, 10 Hz to 7 GHz |
| N9010B-513 | Frequency Range, 10 Hz to 13.6 GHz |
| N9010B-526 | Frequency Range, 10 Hz to 26.5 GHz |
| N9010B-532 | Frequency Range, 10 Hz to 32 GHz |
| N9010B-544 | Frequency Range, 10 Hz to 44 GHz |
| |
| Preamplifier |
| N9010B-P03 | Preamplifier, 3.6 GHz |
| N9010B-P07 | Preamplifier, 7 GHz |
| N9010B-P13 | Preamplifier, 13.6 GHz |
| N9010B-P26 | Preamplifier, 26.5 GHz |
| N9010B-P32 | Preamplifier, 100 kHz - 32 GHz |
| N9010B-P44 | Preamplifier, 100 kHz - 44 GHz |
| |
| Bandwidth |
| N9010B-B40 | Analysis Bandwidth, 40 MHz |
| |
| Performance Options |
| N9010B-DP2 | Digital Processor, 2 GB Capture Memory |
| N9010B-EA3 | Electronic Attenuator, 3.6 GHz |
| N9010B-FSA | Fine Resolution Step Attenuator |
| N9010B-MPB | Microwave Preselector Bypass |
| N9010B-PFR | Precision Frequency Reference |
| N9010B-NF2 | Noise Floor Extension |
| |
| Calibration Options |
| N9010B-A6J | ANSI Z540-1-1994 Calibration |
| N9010B-AMG | Calibration + Uncertainties + Guardbanding (Accredited) |
| N9010B-UK6 | Commercial Calibration Certificate With Test Data |
| |
| Connection Options |
| N9010B-CR3 | Connector, Wideband IF Output |
| N9010B-CRP | Connector, Programmable Rear IF Output |
| N9010B-YAS | Y-Axis Output |
| |
| External Mixing |
| N9010B-EXM | External Mixing |
| |
| Portable packaging |
| N9010B-PRC | Portable Configuration |
| |
| Security - PC features |
| N9010B-SF1 | Security Features, Exclude Launching Programs |
| N9010B-SF2 | Security Features, Prohibit Saving Results |
| N9010B-SSD | Additional Removable Solid State Drive |
| N9010B-SS1 | Additional removable solid state drive, Win10 |
| |
| Application software |
| 89601B | - 89600 VSA 軟件 |
| N6171A | MATLAB 軟件 |
| |
| Accessories |
| 1DVR001A | ROM/CD-R/RW drive |
| 1MSE001A | Mouse |
| MLP001A | Minimum loss pad, 50 to 75 ohm |
| 1CR013A | Rack Slide Kit for 11in, 14in, and 16in Mounting Holes |
| |
| Additional Documentation |
| N9010B-AB1 | Korean localization, user interface and getting started guide |
| N9010B-AB2 | Chinese localization, user interface and getting started guide |
| N9010B-ABE | Spanish localization, user interface and getting started guide |
| N9010B-ABF | French localization, user interface and getting started guide |
| N9010B-ABJ | Japanese localization, user interface and getting started guide |
| N9010B-AKT | Russian localization, user interface and getting started guide |
| |
| Application Software with Subscription |
| N9080EM0E | LTE and LTE-Advanced FDD Measurement Application |
| N9080EM3E | | 頻率 | 10 Hz 至 44 GHz |
|---|
| 頻率選件 | 3.6、7、13.6、26.5、32、44 GHz，使用混頻器可達 1.1 THz |
|---|
| 標準衰減器衰減范圍 | 60 dB |
|---|
| 標準衰減器步進 | 10 dB |
|---|
| 實時帶寬選件 | 無 |
|---|
| 1 GHz 時的 DANL | -172 dBm |
|---|
| 最大分析帶寬 | 40 MHz |
|---|
| 1 GHz 時，1 MHz 頻偏處的相位噪聲 | -136 dBc/Hz |
|---|
| 1 GHz 時，10 kHz 頻偏處的相位噪聲 | -109 dBc/Hz |
|---|
| 1 GHz 時，30 kHz 頻偏處的相位噪聲 | -109 dBc/Hz |
|---|
| 無雜散動態范圍 | 無 |
|---|
| 三階截獲（TOI），1 GHz 時 | +18 dBm |
|---|
| 可用應用 | 是 |
|---|
| 最大實時帶寬 | 無 |
|---|
| 總體幅度精度 | ±0.27 dB |
|---|
| 帶寬選件 | 標配 25，40 MHz |
|---|
| 性能水平 | ◆◆◆◇◇◇ |
|---|
| 應用——蜂窩 | - GSM/EDGE
- LTE/LTE-Advanced
- NB-IoT
- W-CDMA/HSPA/HSPA+
|
|---|
| 應用——通用 | - 89600 VSA 軟件
- 模擬解調
- 噪聲系數
- 相位噪聲
- 脈沖
- EMI
- MATLAB
- Vector Modulation Analysis
|
|---|
| 應用——無線連通性 | - Bluetooth® (BR/EDR/LE4.2/5.0)
- Short Range Communications (ZigBee, Z-Wave)
- WLAN 802.11(a/b/g/j/p/n/ac/af/ah/ax)
|
|---|
| 觸發 | |
|---|
| 2 GHz 時的 DANL，不配備前置放大器 | -150 dBm |
|---|
| 10 GHz 時的 DANL，不配備前置放大器 | -147 dBm |
|---|
選件和升級
選件了解詳細信息: 查看配置指南 | | | Frequency Range | | N9010B-503 | Frequency Range, 10 Hz to 3.6 GHz | | N9010B-507 | Frequency Range, 10 Hz to 7 GHz | | N9010B-513 | Frequency Range, 10 Hz to 13.6 GHz | | N9010B-526 | Frequency Range, 10 Hz to 26.5 GHz | | N9010B-532 | Frequency Range, 10 Hz to 32 GHz | | N9010B-544 | Frequency Range, 10 Hz to 44 GHz | | | | Preamplifier | | N9010B-P03 | Preamplifier, 3.6 GHz | | N9010B-P07 | Preamplifier, 7 GHz | | N9010B-P13 | Preamplifier, 13.6 GHz | | N9010B-P26 | Preamplifier, 26.5 GHz | | N9010B-P32 | Preamplifier, 100 kHz - 32 GHz | | N9010B-P44 | Preamplifier, 100 kHz - 44 GHz | | | | Bandwidth | | N9010B-B40 | Analysis Bandwidth, 40 MHz | | | | Performance Options | | N9010B-DP2 | Digital Processor, 2 GB Capture Memory | | N9010B-EA3 | Electronic Attenuator, 3.6 GHz | | N9010B-FSA | Fine Resolution Step Attenuator | | N9010B-MPB | Microwave Preselector Bypass | | N9010B-PFR | Precision Frequency Reference | | N9010B-NF2 | Noise Floor Extension | | | | Calibration Options | | N9010B-A6J | ANSI Z540-1-1994 Calibration | | N9010B-AMG | Calibration + Uncertainties + Guardbanding (Accredited) | | N9010B-UK6 | Commercial Calibration Certificate With Test Data | | | | Connection Options | | N9010B-CR3 | Connector, Wideband IF Output | | N9010B-CRP | Connector, Programmable Rear IF Output | | N9010B-YAS | Y-Axis Output | | | | External Mixing | | N9010B-EXM | External Mixing | | | | Portable packaging | | N9010B-PRC | Portable Configuration | | | | Security - PC features | | N9010B-SF1 | Security Features, Exclude Launching Programs | | N9010B-SF2 | Security Features, Prohibit Saving Results | | N9010B-SSD | Additional Removable Solid State Drive | | N9010B-SS1 | Additional removable solid state drive, Win10 | | | | Application software | | 89601B | - 89600 VSA 軟件 | | N6171A | MATLAB 軟件 | | | | Accessories | | 1DVR001A | ROM/CD-R/RW drive | | 1MSE001A | Mouse | | MLP001A | Minimum loss pad, 50 to 75 ohm | | 1CR013A | Rack Slide Kit for 11in, 14in, and 16in Mounting Holes | | | | Additional Documentation | | N9010B-AB1 | Korean localization, user interface and getting started guide | | N9010B-AB2 | Chinese localization, user interface and getting started guide | | N9010B-ABE | Spanish localization, user interface and getting started guide | | N9010B-ABF | French localization, user interface and getting started guide | | N9010B-ABJ | Japanese localization, user interface and getting started guide | | N9010B-AKT | Russian localization, user interface and getting started guide | | | | Application Software with Subscription | | N9080EM0E | LTE and LTE-Advanced FDD Measurement Application | | N9080EM3E |
|
|
